SE2432L-R is a highly integrated 2.4 GHz RF front-end module designed for wireless communication systems, offering low noise performance, compact size, and efficient power consumption for IoT and RF applications.

The SE2432L-R datasheet provides detailed technical information, including RF performance characteristics, electrical specifications, application circuits, and recommended operating conditions.

Engineers, designers, and developers can refer to the official datasheet for complete specifications and integration guidance in 2.4 GHz wireless systems.

Key Features of SE2432L-R

• Integrated 2.4 GHz RF front-end module for wireless applications
• Optimized for Wi-Fi, IoT, and ISM band devices
• Low noise figure: 2 dB for improved signal sensitivity
• Operating frequency: 2.4 GHz ISM band
• Supply voltage: 3 V, low power consumption (30 mA typical)
• Integrated PA, LNA, and switch for simplified RF design
• Wide operating temperature range: -40°C to +85°C
• Compact QFN-24 package for space-constrained designs
• CMOS/Si-based technology for stable and reliable performance

Why Choose SE2432L-R?

Choosing SE2432L-R ensures:

• High integration reduces external components and BOM cost
• Improved RF performance with optimized gain and low noise
• Simplified design for faster time-to-market
• Reliable operation in industrial and consumer environments
• Suitable for both professional RF design and IoT development

SE2432L-R Typical Applications

• 2.4 GHz Wi-Fi modules and wireless communication systems
• IoT devices and smart home applications
• Wireless sensors and monitoring systems
• Industrial automation and RF control systems
• Portable and battery-powered RF devices

Specification

The SE2432L-R is a highly integrated 2.4 GHz RF front-end module designed for efficient and reliable wireless communication applications. It features a low noise figure of 2 dB, 3 V operating voltage with 30 mA typical current, and integrated PA, LNA, and RF switch for simplified RF design. With a wide operating temperature range of -40°C to +85°C and a compact QFN-24 package, the SE2432L-R is suitable for Wi-Fi modules, IoT devices, industrial automation, wireless sensors, and battery-powered portable electronics.

FAQ

1. What is SE2432L-R used for?

SE2432L-R is a 2.4 GHz RF front-end module designed for wireless communication systems, including Wi-Fi devices, IoT modules, and industrial RF applications.

2. What frequency band does SE2432L-R support?

It operates in the 2.4 GHz ISM band, which is widely used for Wi-Fi, Bluetooth, and other wireless communication technologies.

3. What are the key advantages of SE2432L-R?

SE2432L-R offers high integration, low noise figure (2 dB), compact size, and low power consumption, making it suitable for space-constrained and energy-efficient designs.

4. What is the operating voltage and current?

The typical operating voltage is 3 V, and the operating current is approximately 30 mA.

5. What package does SE2432L-R come in?

It is available in a compact QFN-24 package, suitable for SMD/SMT assembly.

6. What is the operating temperature range?

The device operates within a temperature range of -40°C to +85°C, making it suitable for industrial applications.

7. Is SE2432L-R suitable for IoT devices?

Yes, it is widely used in IoT, smart home devices, and wireless sensor networks due to its efficiency and integration.

8. Do you provide datasheets or technical support?

Yes, datasheets and basic technical information can be provided upon request. Please contact us for more details.

 You can visit our YouTube channel.

Notice:Any content related to SE2432L-R  provided for “learning or technical study purposes” is for reference only and should not be considered official product documentation or specifications.
