KLMAG1JETD-B041
Basic Information
- Manufacturer: Samsung
- Part Number: KLMAG1JETD-B041
- Product Type: eMMC Flash
- Standard: eMMC 5.1
- Capacity: 16GB
- Package: 153-ball FBGA
- Size: 11.5 × 13 mm
- Condition: New & Original
| MT29F16G08CBABA |
| MT29F32G08CBABA |
| MT29F128G08CBABA |
| MT29F256G08CBABA |
| MT29F1G01ABBFDWB-IT:F |
| MT29F2G08ABAFAWP:F |
We support Escrow payment and bank transfer (T/T). With Escrow, funds are held by a third-party platform and only released after you confirm receipt of the goods, ensuring transaction security.
Description
KLMAG1JETD-B041 is a high-performance eMMC storage solution designed for reliable embedded applications, offering efficient data handling and stable NAND flash operation in compact mobile and industrial devices.
KLMAG1JETD-B041 – eMMC 5.1 Embedded Storage Overview
KLMAG1JETD-B041 is an embedded eMMC storage solution designed for use in mobile and embedded systems, supporting efficient data handling and integrated NAND flash storage functionality.
Overview of KLMAG1JETD-B041
The KLMAG1JETD-B041 is an embedded storage device developed by Samsung Electronics. It supports the eMMC 5.1 interface standard and integrates NAND flash memory with a controller in a compact FBGA package.
This device is designed for embedded applications requiring stable data storage and simplified system integration. It includes standard eMMC features such as error correction, wear leveling, and bad block management.
Key Features of KLMAG1JETD-B041
- Supports eMMC 5.1 interface (JEDEC standard)
- High-speed interface with HS400 mode (host dependent)
- Integrated NAND flash and controller architecture
- Supports command queuing and cache features
- Enhanced strobe mode support (platform dependent)
- Built-in ECC, wear leveling, and bad block management
- Secure write protection support
- Backward compatible with earlier eMMC standards
Key Specifications
| Parameter | Details |
| Capacity | 16GB |
| NAND Flash Type | 128Gb × 1 |
| Interface | eMMC 5.1 |
| Bus Width | 1-bit / 4-bit / 8-bit |
| Clock Frequency | Up to 200MHz |
| Package | 153-ball FBGA |
| Package Size | 11.5 × 13 × 0.8 mm |
| Interface Voltage | 1.7V ~ 1.95V / 2.7V ~ 3.6V |
| Memory Voltage | 2.7V ~ 3.6V |
| Operating Temperature | -25°C ~ +85°C |
Applications of KLMAG1JETD-B041
- Smartphones and tablets
- Embedded systems
- Industrial control devices
- Smart home and IoT devices
- Automotive infotainment systems
- Multimedia and set-top devices
Why Choose Us
- Supply of Samsung memory components through standard distribution channels
- Stable supply capability
- Flexible order quantities
- Worldwide shipping support
- Standard quality control procedures
FAQ
Q1: What is the actual usable capacity?
A: The nominal capacity is 16GB. Usable capacity may vary depending on system configuration and formatting.
Q2: Is this device compatible with older eMMC versions?
A: Yes, it is designed to be backward compatible with earlier eMMC standards.
Q3: What package type does this product use?
A: It uses an FBGA package (153-ball), suitable for compact PCB designs.
Q4: Does it support high-speed data transfer?
A: It supports high-speed modes such as HS400. Actual performance depends on the host system.
Q5: Is it suitable for industrial applications?
A: It can be used in embedded and industrial environments. Operating conditions should be verified for the specific use case.
Q6: What voltage does it require?
A: Voltage requirements depend on system design and configuration. Refer to official documentation for details.
Q7: Does it include data reliability features?
A: Yes, standard eMMC features such as error correction and wear leveling are supported.
Q8: Can it be used in IoT devices?
A: Yes, it is commonly used in embedded and IoT-related applications.
